Features ; MASTECH MS8910 LCR METERS
- Display 3000 counts
- Auto Ranging
- Auto Power Off
- Data Hold
- Low Battery Display
- Auto Scanning
- Diode Check Open Voltage 2.8V
- Diode Testing Current 2mA
- Continuity Buzzer <30Ω
Specifications ; MASTECH MS8910 LCR METERS
Specifications | Range | Resolution | Accuracy |
Resistance | 300Ω/3kΩ/30kΩ/300kΩ/3MΩ | 0.1Ω/1Ω/10Ω/100Ω/1kΩ | ±(1.0%+2) |
30MΩ | 10kΩ | ±(1.2%+3) | |
Capacitance | 3nF/30nF/300nF/3μF/30μF | 1pF/10pF/100pF/1nF/10nF | ±(2.0%+3) |
300μF/3mF/30mF | 0.1μF/1μF/10μF | ±(3.0%+3) |
General Specs
- Power Supply: 1×3V CR2032 Battery
- Product Size : 175mm×32mm×20mm/6.89″×1.26″×0.79″
- Product Weight: 48g/0.10lb
- Certificate: CE / ETL /RoHS
Working Specification: MASTECH MS8910 LCR METERS
Accessories
- Spare test pins
- Battery and User’s manual
APPLICABILITY
- For testing SMD elements
- In case of malfunction search
- For the realization of profesional and hobby projects
- For precise and accurate measurement
Resources
Package includes:
- 1 x Mastech MS8910 Smart LCR Meter – Original
- 1 X Spare Test Pin
